Sprinkler Pipe (A135/A795)

OVERVIEW

Overview

Trust Bull Moose® when it comes to protecting lives and property. As the leading manufacturer of steel sprinkler pipe for fire suppression, we understand that there are no second chances in firefighting. You need products of enduring quality and exceptional strength—that’s Bull Moose Schedule 40 Sprinkler Pipe.

Bull Moose Advantages

UL listed (US & Canada) and FM approved
All Bull Moose pipe carries a UL Environmental Product Declaration (EPD).
ASTM A135 and A795 Type E, Grade A Certified
Complies with NFPA-13, 13R and 14
Industry-leading hydraulic characteristics
All pipe NDT weld testing
CRR of 1.0 and greater
Exclusive maker of pre-painted & stenciled Reddi-Pipe®
Custom length options
EddyGuard™ bacterial-resistant internal coating for the Eddy Pipe family of sprinkler pipe
Eddy Pipe advantages include reliable availability and the fastest delivery through eight North American sites.

Relevant Documentation

Sprinkler Spray Sway Brace Chart

Sprinkler Sway Brace Chart

Bull Moose Tube has a 60-year history of being a thoroughly knowledgeable supplier of the products we sell. And as one of the leading manufacturers of sprinkler pipe in North America, we have quite a bit of knowledge to share.

Part of that process involves providing thorough technical data to fire protection contractors, engineers, architects, fire prevention officers, municipal agencies, and others involved in fire suppression systems.

A simple but vital component of many fire sprinkler systems is the sway brace. Sway bracing has a vital purpose in systems requiring seismic protection. The sway braces (in conjunction with other devices such as anchors and restraint hangers) help to control horizontal movement of the fire sprinkler pipe in order to withstand the stresses of a seismic event.

The braces—as well as all of the constituent parts of a fire sprinkler system)—have maximum allowable loads. This is the maximum amount of force that any part of the brace can handle. We have developed this chart to aid professionals who are evaluating NFPA 13 seismic bracing requirements.

Bull Moose Schedule 40 sprinkler pipe is a mainstay in the fire protection field. We provide several exclusive technologies to the industry, including our EddyGuard II internal coating. This antimicrobial coating helps prevent the bacterial growth inside of sprinkler pipe that can interfere with proper flow.

Another Bull Moose Tube exclusive is Redd-Pipe, which arrives onsite fully painted and stenciled for UL/FM and AHJ compliance.

Our Eddy Pipe family of products (such as Eddy Flow, and EddyThread Schedule 40) are long-time proven performers in the fire suppression industry.

Bull Moose sprinkler pipe is available in both standard and custom lengths and diameters. Products are available to meet ASTM A135 and A795 Type E, Grade A., and to comply with NFPA-13, 13R and 14. All our sprinkler pipe undergoes NDT weld testing.

Document Text:

Bull Moose Tube EDDY FLOW Steel Pipe Joined by Threading, Bonding or Compression/Grooved Couplings Chart

(Text Chart must be viewed on Desktop)

Max Zone of Influence Load (Fpw) lbs.						Max. Transverse and 4-way Brace Spacing ( ft.) *** According to HLF for the 2006 & 2009 IBC ( ASCE 7-05 ) & Cp for NFPA-13 shown in BOLD TYPE
Pipe Size	Traverse Space Bracing*
Pipe Size	20 ft.	25 ft.	30 ft.	35 ft.	40 ft.	0.25	0.50	0.75	1.00	1.25	1.5	1.75	2.00	2.25	2.5	2.75	3.00
1 1/4	136	109	89	76	64	40	40	37	32	39	26	24	23	21	20	19	18
1 1/2	232	185	152	130	109	40	40	40	35	31	29	27	25	23	22	21	20
2	372	297	244	209	175	40	40	40	38	34	31	28	27	25	24	23	22
2 1/2	549	440	360	309	258	40	40	40	40	37	34	31	29	28	26	25	24
3	809	648	531	455	381	40	40	40	40	37	34	31	29	28	26	25	24
4	1544	1235	1012	867	726	40	40	40	40	40	37	34	32	30	29	28	26

Bull Moose Tube EDDYTHREAD 40 Steel Pipe Joined by Threading, Bonding or Compression/Grooved Couplings

(Text Chart must be viewed on Desktop)

Max Zone of Influence Load (Fpw) lbs.						Max. Transverse and 4-way Brace Spacing ( ft.) *** According to HLF for the 2006 & 2009 IBC ( ASCE 7-05 ) & Cp for NFPA-13 shown in BOLD TYPE
Pipe Size	Traverse Space Bracing*
Pipe Size	20 ft.	25 ft.	30 ft.	35 ft.	40 ft.	0.25	0.50	0.75	1.00	1.25	1.5	1.75	2.00	2.25	2.5	2.75	3.00
1	119	95	78	67	56	40	40	36	31	28	25	24	22	21	20	19	18
1 1/4	218	175	143	123	103	40	40	40	35	31	28	26	25	23	22	21	20
1 1/2	312	250	205	175	147	40	40	40	37	33	30	28	26	25	23	22	21
2	518	414	339	291	243	40	40	40	40	36	33	30	29	27	26	24	23

Eddy Flow Data Sheet

Eddy Flow Brochure

UV Coating Brochure

EddyThread 40 Data Sheet

Document Text:

EDDYTHREAD SPRINKLER PIPE SUBMITTAL DATA SHEET

APPROVALS AND SPECIFICATIONS

ASTM A135, Grade A
ASTM A795, Type E, Grade A
Pressure rated to 300 psi
Underwriters Laboratories—United States of America
Underwriters Laboratories—Canada
Factory Mutual
NFPA-13
NFPA-13R
NFPA-14
CIVIL DEFENSE APPROVAL— United Arab Emirates
Made in the United States of America
UL, ULC & FM listed for roll-groove, plain-end and welded joints for wet, dry, preaction and deluge sprinkler systems.
LEED v4 Certified

FINISHES AND COATINGS

Eddythread Sprinkler Pipe receives an OD mill coating of water-based paint which has corrosion protection consistent with a painted carbon steel product, (i.e., it would be expected to resist corrosion for an extended and indefinite period in a clean and dry environment and, as environmental conditions deteriorate, the corrosion protection would also diminish).
Eddythread Sprinkler Pipe (black) receives an ID mill coating of Eddy Guard II MIC preventative coating. EG2 has been tested at independent laboratories to resist bacterial growth and maintain minimal bacterial count after multiple flushes (25) of the pipe.
Eddythread Sprinkler Pipe when Hot Dip Galvanized by ASTM A123 and supplied by Bull Moose Tube is UL listed and FM approved.

PRODUCT IDENTIFICATION

Every length of Bull Moose fire sprinkler pipe features large, easy-toread, continuous stenciling, clearly identifying the manufacturer, type of pipe, size, and length.
(Text Chart must be viewed on Desktop)

Nominal Pipe Size (inches)	1	1-1/4"	1-1/2"	2
O.D. (in)	1.295	1.650	1.900	2.375
I.D. (in)	1.083	1.418	1.654	2.123
Empty Weight (lb/ft)	1.461	2.070	2.547	3.308
Water Filled Weight (lb/ft)	1.860	2.754	3.468	4.842
C.R.R.*	1.00	1.00	1.00	1.00
Pieces per Lift	70	51	44	30

*Calculated using Standard UL CRR formula, UL Fire Protection Directory, Category VIZY

Sprinkler Pipe Brochure

Schedule 10, 30, & 40 Sprinkler Pipe Data Sheet

Sprinkler Pipe Bundle Chart

Environmental Product Declaration

Antimicrobial Protection

To Keep Pipes Flowing Freely

Bull Moose Tube’s exclusive EddyGuard II® bacteria-resistant MIC coating was the first in the industry to investigate CPVC compatibility via certified 3rd-party lab testing—with further testing through Spears Manufacturing, NSF and FM. Since the introduction of EddyGuard II® in 2007, there’s been not one claim of CPVC compatibility problems, not one claim of MIC problems. That’s solid Bull Moose reliability.

Reddi-Pipe

Get Reddi to Save

Sprinkler pipe that saves you time and money, because it arrives at your shop ready to use, complete with a durable finish in red, black—or your choice of custom colors! This saves you all the time and labor costs associated with sending pipe out for powder coating (plus the hassle of re-stenciling when it comes back in)…not to mention the costs of freight, and the powder coating itself.

Most importantly, since your parts never leave your shop, you never lose traceability.

Reddi-Pipe is fully stenciled for UL/FM and AHJ compliance.
Easy to weld (unlike powder coating).
Protected by our exclusive EddyGuard II antimicrobial internal coating.
Available in all standard diameters.
Custom length options.
Certified to ASTM A135 and A795 Type E, Grade A
Complies with NFPA-13, 13R and 14
Industry-leading hydraulic characteristics
Pressure ratings exceeding 300 psi
CRR of 1.0 and greater
All pipe endures NDT weld testing
Competitively priced
We provide prompt shipment from production facilities across the U.S.

With Reddi-Pipe, just fabricate the system, use our touch-up paint to finish off dings and scratches…and deliver parts to the job site for installation. You avoid all the costs and headaches associated with powder-coating and re-stenciling!

Bottom line: these Bull Moose® sprinkler pipes are Reddi…to save you time and money.

COST OF	CONVENTIONAL SPRINKLER PIPE		REDDI-PIPE
COST OF	Money/Time	Associated Expense	Associated Time	Associated Expense	Associated Time
Outbound Shipping for Powder Coating:	$	hrs	$0	0 hrs.
Powder Coating:	$	hrs	$0	0 hrs.
Inbound Shipping from Powder Coating:	$	hrs	$0	0 hrs.
Re-Stenciling:	$	hrs	$0	0 hrs.
Labor Costs for Above:	$		$0	0 hrs.*
YOUR SAVINGS:	$ 0 in Expenses	Plus 0 Hours of Labor	$0	0 hrs.
